Compatibility
Intel LGA1700/1200/1151/1150/1155/1156
AMD AM5/AM4
TDP
220W
Overall Dimension
120×75×151mm (L×W×H)
Heatsink Material
4×Ф6mm Heatpipe(Direct Touch)+Aluminum Fin
Weight
650g (heatsink+fan)
Fan Dimension
120×120×25mm
Fan Speed
600±200~1500±10%RPM
Max. Air Flow
70CFM
Max. Static Pressure
2.15mmH2O
Noise
28.9dB(A) Max.
Rated Voltage
12VDC (4pin PWM) / 5V (3pin ARGB)
Operating Voltage
10.8～13.2VDC
Started Voltage
7VDC
Rated Current
0.2A
Power Input
2.4W
Bearing Type
Hydraulic Bearing
Connector
4Pin PWM / 3pin ARGB
